Toothing crossed and milled.
Application range:
Wood with nails, metal and chipboard from 10,0 - 250,0 mm material thickness, gas concrete from 10,0 - 250,0 mm,
plastics / FRP and profiles from 5,0 - 60,0 mm.
Rated input power: 1100W
Output power: 550W
Strokes in idle: 0 - 2600rpm
Saw blade stroke: 28mm
Pendulum stroke levels: 0
Weight (without power cable): 3.9kg
Cable length: 4m
Vibration
Sawing chipboards: 14m/s²
Uncertainty of measurement K: 1.5m/s²
Noise emission
Sound pressure level: 89dB(A)
Sound power level (LwA): 100dB(A)
Uncertainty of measurement K: 3dB(A)
Slim machine with soft-grip handle for comfortable sawing in every working position
Robust aluminium die-cast gear housing, coated for optimum handling
Metabo Quick for changing saw blades without tools
Saw blade rotatable by 180° for working comfortably overhead
Depth guide can be adjusted without tools for ideal utilisation of the saw blade and diverse applications such as plunge cuts
Vario (V)-Electronics for working with customised stroke rates for the materials used
Continuous speed control trigger c/w locking function for continuous operation
Gear protected against dust and water splashes
Wide range of uses thanks to the adapted Metabo saw blade range
Quick sawing progress thanks to powerful motor
https://youtu.be/GwNQSu9a7rY
Light, extremely handy saw for one or two handed operation
Especially suitable for working in difficult to reach places
The Metabo 12 Volt class - lightweight, yet powerful
Unique Metabo brushless motor for quick work progress and highest efficiency for any application
Variospeed (V) Electronics for working with customised stroke rates for the materials used
Saw blade rotatable by 180° for working comfortably overhead
Extended range of application thanks to unique Quick retainer for sabre saw blades and jigsaw blades
Depth guide can be adjusted without tools for ideal utilisation of the saw blade and diverse applications such as plunge cuts
Integrated LED work light for optimum illumination of the cutting line
Wide range of uses thanks to the adapted Metabo saw blade range
Characteristics
Battery voltage: 12 V
Strokes in idle: 0 - 3000 rpm
Saw blade stroke: 16 mm
Weight (including battery pack): 1.6 kg
Vibration
Sawing chipboards17 m/s²
Sawing wooden beam14.5 m/s²
Uncertainty of measurement K1.5 m/s²
Noise emission
Sound pressure level78 dB(A)
Sound power level (LwA)89 dB(A)
Uncertainty of measurement K3 dB(A)
Sjá nánar: https://youtu.be/4xxlqTp6MIY
Characteristics
Battery voltage: 18 V
Strokes in idle: 0 - 2700 rpm
Saw blade stroke: 32 mm
Weight (including battery pack): 3,2 kg
Powerful sabre saw with low weight and angled soft grip handle for high working comfort
Unique Metabo brushless motor for quick work progress and highest efficiency for any application
Robust die-cast aluminium gear housing, coated for optimum handling
Variospeed (V) Electronics for working with customised stroke rates for the materials used
Continuous speed control trigger c/w locking function for continuous operation
Saw blade rotatable by 180° for working comfortably overhead
Metabo Quick for changing saw blades without tools
Depth guide can be adjusted without tools for ideal utilisation of the saw blade and diverse applications such as plunge cuts
Integrated LED work light for optimum illumination of the cutting line
Gear protected against dust and water splashes
Wide range of uses thanks to the adapted Metabo saw blade range
Battery packs with capacity display for checking the charge status
Ultra-M technology: highest performance, gentle charging and 3 years of warranty on the battery pack.
Light, extremely handy saw for one or two handed operation
Especially suitable for working in difficult to reach places
Unique Metabo brushless motor for quick work progress and highest efficiency for any application
Variospeed (V) Electronics for working with customised stroke rates for the materials used
Saw blade rotatable by 180° for working comfortably overhead
Extended range of application thanks to unique Quick retainer for sabre saw blades and jigsaw blades
Depth guide can be adjusted without tools for ideal utilisation of the saw blade and diverse applications such as plunge cuts
Integrated LED work light for optimum illumination of the cutting line
Wide range of uses thanks to the adapted Metabo saw blade range
Battery packs with capacity display for checking the charge status
Ultra-M technology: highest performance, gentle charging and 3 years of warranty on the battery pack.
Battery voltage: 18V
Strokes in idle: 0 - 3100rpm
Saw blade stroke: 13mm
Weight (including battery pack): 1.7kg
Vibration
Sawing chipboards: 10m/s²
Uncertainty of measurement K: 1.5m/s²
Noise emission
Sound pressure level: 80dB(A)
Sound power level (LwA): 91dB(A)
Uncertainty of measurement K: 3dB(A)
Light, extremely handy saw for one or two handed operation
Especially suitable for working in difficult to reach places
Metabo Quick for changing saw blades without tools
Extended range of application thanks to unique Quick retainer for sabre saw blades and jigsaw blades
Depth guide can be adjusted without tools for ideal utilisation of the saw blade and diverse applications such as plunge cuts
Integrated LED work light for optimum illumination of the cutting line
Wide range of uses thanks to the adapted Metabo saw blade range
Battery packs with capacity display for checking the charge status
Ultra-M technology: highest performance, gentle charging and 3 years of warranty on the battery pack.
